Mercury Analyzer – Mercury Ultra tracer

The UT-3000 Mercury Ultratracer is a compact and reliable instrument for measuring mercury in gases at ultra trace levels according to the EN 15852. Utilizing the high performance GoldTrap amalgamation module and an optimized state-of-the-art AA-mercury vapor detector the UT-3000 Ultratracer offers detection limits at sub-ng/m3 (ppt – parts per trillion) levels.

SPECIFIC FEATURES:

• Measuring of Total Gaseous Mercury (TGM) in air and other gases such as natural gas, hydrogen,
  etc. at ultra trace levels
• Well proven detection method: Cold Vapor Atomic Absorption Spectrometry (CVAAS)
• Preconcentration of mercury using the proprietary Mercury Instruments GoldTrap
• Detection limit at sub-ng/m3 (ppq-parts per quadrillion) level, far superior to other instruments on
  the market
• Offers excellent long-term stability of measurement
• No need for a long optical cell thanks to enhanced sensitivity of the UV-detector in the UT-3000
• High frequency driven electrode-less mercury low pressure lamp as UV light source provides high
  sensitivity, precision and stability
• Contrary to the fluorescence detection method, the UT-3000 does not require expensive carrier gases
• Insensitive to interferences caused by the quenching effect
• The UT-3000 offers sensitivity and detection limits superior to other mercury analyzers on the market
  using similar technologies

Portable AQM Real time internal data logging systems (EDC, USA)

Specific continuous gas measurement monitors for quantitative determination of Mercury concentrations in air, gas, natural gas or liquid samples in various applications:

• Air quality monitoring
• Environmental surveillance
• Mercury contamination in ecosystems
• Quality control
• Laboratory analysis

Description:

A compact and reliable measuring tool with a specialized trapping system.

– Mercury GoldTrap Amalgamation module:

• Offers excellent long-term stability of measurement.
• Enhances sensitivity of the analyzer and dismisses the necessity of a long optical cell for the detection phase.
• A high frequency electrode-less mercury low pressure lamp as a UV light source provides high sensitivity, precision and stability.
• Unlike with the fluorescence detection method, the analyzer does not require expensive operation gases, nor suffer from negative interferences caused by the quenching effect.
• The analyzer offers sensitivity and detection limits superior to other mercury analyzers on the market using similar technologies.
